AMAT Applied Materials 0130-11002 Digital Input/Output Card

AMAT Applied Materials 0130-11002 Digital Input/Output Card

Product Details Introduction

AMAT 0130-11002 Digital Input/Output Card

Product Overview

AMAT 0130-11002 Digital Input/Output Card is a type of I/O interface module in Applied Materials semiconductor equipment, used to achieve digital signal interaction between the device and external sensors and actuators. As a bridge between the control system and on-site signals, it can collect digital input signals (such as switch values and status signals) and output digital control signals (such as relay control and action triggering), thereby completing equipment logic control and interlock protection.

Technical parameters (inferred general characteristics)

Input channel: Multiple digital inputs, supporting dry contacts or active signals

Output channel: Multi channel digital output, capable of driving relays, indicator lights, solenoid valves, etc

Electrical characteristics: commonly used 24VDC industrial control level, with overcurrent, overvoltage and isolation protection

Signal isolation: using optocouplers or relays for isolation to prevent interference from affecting the core control unit

Communication interface: connected to the controller module through a backplane bus or standard interface

Reliability: Meet the high stability requirements for long-term operation in semiconductor production environments

Application scenarios

Signal acquisition and control of semiconductor equipment

Collect status signals of chamber door locks, vacuum switches, temperature controllers, gas valves, etc

Output control signals to drive vacuum valves, electromagnetic actuators, and alarm devices

Security interlock system

Collaborate with relay modules and controller modules to achieve multi-level interlocking control of equipment

Prevent the startup of critical subsystems under unsafe conditions

Process automation logic

Support sequential control of process steps (such as vacuuming before gas flow)

Trigger the action signal to ensure that the process flow conforms to the preset logic

Equipment diagnosis and maintenance

Provide input/output status feedback for engineers to locate equipment faults

When upgrading or expanding devices, I/O channels can be added to enhance control capabilities

AMAT Applied Materials 0130-11002 Product imag
