GIDINGS&LEWIS 501-03209-00 Execution Control Board

GIDINGS&LEWIS 501-03209-00 Execution Control Board

Product Details Introduction

GIDINGS&LEWIS 501-03209-00 Execution Control Board

Product Overview

The Giddings&Lewis 501-03209-00 Execution Control Board is a critical control module for CNC machine tools, mainly responsible for action control and instruction issuance at the execution level. It is usually installed in CNC systems or electrical control cabinets, receiving instructions from the upper CPU board or control unit, and converting them into control signals for servo drives, actuators, and peripheral devices. It is the core bridge connecting "logical control" and "actual execution" in CNC systems.

Technical Features

Instruction execution: Convert the motion, processing, or logic commands issued by the upper computer into actual control signals.

Multi channel control: capable of managing multiple servo axes, I/O interfaces, and peripheral devices simultaneously.

Strong real-time performance: ensuring fast response and high precision of machine tool motion control.

Modular design: Supports plug-in installation for easy system expansion and replacement.

Anti interference capability: optimized circuit design, suitable for complex environments of heavy-duty machine tools.

Application field

CNC boring and milling machines

Manage the execution control of multi axis linkage such as workbench, spindle, and tool holder to ensure high-precision machining of large workpieces.

Vertical lathe and milling composite center

Coordinate the actuator actions in multi process composite machining such as turning, milling, and drilling.

Servo drive control

As an intermediate layer between the CPU and the servo driver, it controls the speed, position, and acceleration of the motor.

Automatic production line

Used for controlling the execution unit of machine tools in the production line, ensuring synchronization with the actions of upstream and downstream equipment.

Machine tool upgrade and renovation

In the numerical control transformation of old G&L equipment, the core execution control module is used to improve the performance of the machine tool.

Product imag
