Product Details Introduction

GIDINGS&LEWIS 502-02307-00 Rotary Transformer Module

Product Overview

The Giddings&Lewis 502-02307-00 rotary transformer module is an interface module for position/velocity detection and feedback, mainly used in conjunction with rotary transformer (Resolver) sensors. Rotary transformer is a highly reliable rotating position detection device commonly used in CNC machine tools and servo drive systems. This module is responsible for parsing signals from rotary transformers and converting them into standard feedback signals that can be recognized by numerical control systems or servo controllers.

Technical Features

Signal conversion: Convert the sine/cosine analog signal of the rotary transformer into a digital position signal.

High precision feedback: achieve real-time and high-precision detection of motor angle and speed.

Stable and reliable: adaptable to strong interference environments in industrial sites, with strong anti vibration capabilities.

Modular design: Installed in the G&L control system rack for easy maintenance and replacement.

Strong compatibility: compatible with various servo motors, spindle motors, and CNC systems.

Application field

CNC machine tool spindle control

Used for spindle angle and speed detection of large boring machines, milling machines, turning centers and other equipment to ensure machining accuracy.

Servo drive system

Provide high-precision position feedback in the feed servo motor system to achieve closed-loop control.

Machine tool positioning system

As a key feedback link, ensure the precise positioning of components such as workbenches and tool holders.

Machine tool transformation and upgrading

In the numerical control transformation of old equipment, it is used to add position detection and feedback functions.

Testing and Diagnosis

During the maintenance process of the machine tool, the rotary transformer module can be used for monitoring the feedback signals of the motor and control system.

Product imag
