Giddings&Lewis 401-34201-13 DS100 Centurion Servo Drive

Product Overview

401-34201-13 belongs to the Giddings&Lewis DS100 series servo drive and is used in conjunction with the Centurion control platform. This driver is used to control brushless AC servo motors, with high response speed and precise control capability, and is the core driving unit in CNC systems.

Technical parameters (typical features)

Input power supply: three-phase AC, commonly 230V or 460V industrial power supply

Drive type: Brushless AC servo drive

Control mode: speed loop, position loop, torque control mode

Output power range: Suitable for small and medium power servo motors (usually in the range of 1-7 kW)

Protection functions: overvoltage, undervoltage, overcurrent, and over temperature protection

Application scenarios

CNC machine tool: As a feed axis or spindle servo driver, it ensures the speed and position accuracy of the machine tool during the machining process.

Automated production line: used for motor control of automated equipment such as assembly, packaging, and handling.

Industrial robots: provide stable driving for joint servo motors to achieve precise motion control.

Specialized equipment: Provides high dynamic response drive in textile machinery, printing machinery, and electronic manufacturing equipment.

Product advantages

High dynamic performance: Fast response, meeting complex trajectory and high-speed positioning requirements.

Strong reliability: Industrial grade design, supporting long-term continuous operation.

Modular structure: facilitates integration with Centurion controllers and simplifies system architecture.

Good security: equipped with comprehensive protection functions to reduce the risk of equipment damage.

Good maintainability: capable of inspection, repair, and replacement, extending the lifespan of the entire machine.

Product imag
