1、 Product Overview

The GIDDINGS&LEWIS 502-03679-02 encoder module is an input module used for motion control and position detection,

The main function is to receive pulse signals from rotary or linear encoders and convert them into digital data that can be recognized by the control system.

It is commonly used in CNC machine tools, automated production lines, and robot systems to achieve speed monitoring, position feedback, and closed-loop control.

2、 Technical parameters (typical indicators, subject to actual conditions)

Module type: Encoder input module

Signal support: Incremental encoders (A/B/Z channels), some models can support orthogonal signals

Input voltage: 5V/12V/24V TTL or differential signal

Resolution: Depending on the accuracy of the external encoder, it can support up to several thousand to millions of pulses per revolution

Number of channels: Multi channel input, supporting dual encoder signal access

Response frequency: High frequency input, typically up to 200kHz-1MHz

Isolation method: Channel and control bus are electrically isolated

Interface method: Modular slot, compatible with GIDDINGS&LEWIS system bus

Features

Position capture and counting

Speed and direction determination

Zero point reset/reference point detection

Support real-time closed-loop control

Product imag
