Product Details Introduction

GIDDINGS&LEWIS M.1300.4145 output module

1、 Product Overview

GIDDINGS&LEWIS M.1300.4145 output module is a signal and control interface unit in industrial automation systems, used to convert logical instructions issued by the controller into executable electrical signals, driving external loads such as relays, contactors, indicator lights, actuators, etc. This module has the characteristics of fast response speed, high reliability, and strong anti-interference ability, and is commonly used in CNC systems, automated production lines, and mechatronics equipment.

2、 Technical parameters (typical indicators, subject to actual version)

Module type: Digital output module

Number of channels: Multi channel (commonly 8 or 16 channels)

Output form: transistor/relay output (depending on configuration)

Voltage level: DC 24V or AC 110/220V compatible

Output current: Single channel 0.5A-2A (typical value)

Isolation method: Optocoupler isolation to enhance anti-interference ability

Response time:<1ms

Installation method: Plug in modular design, easy to replace and expand

Interface: Compatible with GIDDINGS&LEWIS main control system bus

3、 Application scenarios

Numerical Control Machine Tool Control

Control peripheral devices such as spindle start stop, coolant pump, work lights, alarm, etc.

automated production line

Realize the control of conveyor belts, actuator cylinders, and robotic arm end effectors in the production line.

process control system

Used for on-off driving of valves, electromagnets, and motors.

robot system

Control the linkage of end tool fixtures, signal lights, and process equipment.

Industrial Inspection and Testing Platform

Output control signals to achieve automation of testing processes.

Product imag
