Product Details Introduction

Product Overview

The Giddings&Lewis 502-03782-00 input encoder module is one of the key components of the PiC900 series control system, mainly used to receive and process feedback signals from multi-channel incremental encoders. It can provide precise position and velocity feedback for CNC machine tools, servo systems, and automation equipment, and is the core module in high-performance motion control systems.

Product Features

Multi channel support

Supports up to 4 channels of incremental encoder input, suitable for multi axis control systems.

Each channel can simultaneously process A/B phase and index pulse signals.

High precision counting

Built in 24 bit up/down counter, capable of achieving high-resolution pulse counting.

Provide position locking function, which can be triggered by encoder index pulse or external fast input.

high speed signal processing

The standard version can support input frequencies up to 250 kHz.

The high-speed version can handle input frequencies up to 2.5 MHz, making it suitable for high-speed servo systems.

Strong signal compatibility

Supports differential input and single ended input methods, suitable for different encoder types.

Wide voltage input range, compatible with encoders of different specifications.

Industrial environment adaptability

Has good electromagnetic compatibility and anti-interference performance, suitable for complex industrial environments.

Suitable for long-term stable operation through anti vibration and anti impact testing.

The working temperature range is 7 ℃ to 55 ℃, the storage temperature is -40 ℃ to 85 ℃, and the humidity is 5% to 95% (no condensation).

Easy installation and maintenance

Modular design, can be used by inserting the PiC900 backplane.

Provide LED status indication for easy diagnosis and maintenance.

The wiring method is flexible, using card edge connectors and screw terminals.

Product imag
