GIDINGS&LEWIS NSM3406 brushless servo motor

GIDINGS&LEWIS NSM3406 brushless servo motor

Product Details Introduction

GIDDINGS&LEWIS NSM3406 brushless servo motor

1、 Product Overview

GIDDINGS&LEWIS NSM3406 is a brushless AC servo motor (BLDC) designed for high-precision motion control systems. This motor has the characteristics of high efficiency, low inertia, high dynamic response, and long lifespan. When combined with servo drives, it can achieve precise speed, position, and torque control. It is widely used in CNC machine tools, automation equipment, robot systems, and other high-performance motion control fields.

2、 Technical parameters (typical indicators, specific subject to physical object)

Motor type: Brushless AC servo motor (BLDC)

Rated power: 500W-2kW (depending on configuration)

Rated voltage: AC 200-240V or DC 24-48V (depending on model)

Rated speed: 0-3000 rpm (customizable)

Feedback type: incremental encoder or absolute value encoder

Torque characteristics: high starting torque, stable continuous operation

Inertia: Low inertia design for fast dynamic response

Cooling method: air cooling or natural cooling

Installation method: flange installation, standard rack interface

Protection level: IP54 or above (depending on model)

3、 Application scenarios

CNC machine tool

Drive the spindle or feed servo to achieve high-speed and high-precision machining and complex trajectory interpolation.

Automatic production line

Control the conveying device and end effector of the robotic arm to improve production efficiency and positioning accuracy.

robot system

Used for joint movements to achieve high-speed and high-precision motion control.

Packaging and Printing Machinery

Provide precise tension control, positioning, and winding functions.

Testing and experimental equipment

Provide high reliability positioning and speed control for precision motion platforms.

Product imag
