GIDINGS&LEWIS 502-03679-00 Thermocouple Module

GIDINGS&LEWIS 502-03679-00 Thermocouple Module

Product Details Introduction

GIDDINGS&LEWIS 502-03679-00 Thermocouple Module

1、 Product Overview

GIDDINGS&LEWIS 502-03679-00 thermocouple module is a temperature measurement input module used in industrial automation systems. It converts temperature signals into digital signals recognizable by the controller by connecting different types of thermocouples (such as J, K, T, E, etc.), providing high-precision process temperature monitoring and closed-loop control functions. This module is widely used in CNC machine tools, process control, manufacturing, and experimental testing equipment.

2、 Technical parameters (typical indicators, specific subject to physical object)

Module type: thermocouple input module

Support sensors: J, K, T, E, N, R, S, B and other types of thermocouples

Number of channels: Multi channel input (commonly 4/8 channels)

Input range: -200 ℃ to+1800 ℃ (depending on thermocouple type)

Resolution: 0.1 ℃ or higher accuracy

Accuracy: ± 0.5% full scale (typical)

Cold end compensation: Built in automatic compensation function to ensure measurement accuracy

Isolation method: Channel and system bus isolation to enhance anti-interference capability

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS 502 series system bus

Sampling speed: typical 100ms-500ms/channel

3、 Application scenarios

Numerical Control Machine Tools and Heat Treatment Equipment

Temperature detection and protection of spindle bearings, cutting tools, heat treatment furnaces, etc.

process industry

Used for temperature monitoring and automatic control in the chemical, metallurgical, and energy industries.

Automatic production line

Perform temperature closed-loop regulation on injection molding, printing, textile and other process links.

Experimental and testing platform

Used for precise temperature measurement in scientific research or quality inspection systems.

Energy and Power Systems

Applied to temperature monitoring of equipment such as boilers and turbine units to ensure safe operation.

Product imag
