GIDINGS&LEWIS 502-03420-00 servo interface module

GIDINGS&LEWIS 502-03420-00 servo interface module

Product Details Introduction

Product Overview

The Giddings&Lewis 502-03420-00 servo interface module is a key module in the PiC series control system, used to connect servo drives and control systems. It is responsible for converting the motion commands issued by the controller into recognizable control signals for the servo drive, while receiving feedback signals from the servo motor to achieve closed-loop control. This module is one of the core components for achieving high-precision, multi axis motion control.

Product Features

Multi axis support

Multiple servo drives can be connected simultaneously to achieve multi axis synchronous control.

Supports multiple types of servo motors and feedback devices, such as incremental encoders and absolute encoders.

Closed loop control capability

Receive feedback signals from servo drives to achieve closed-loop control of position, speed, and torque.

Provide high-precision motion control and fast response capability.

high speed signal processing

Support high-speed data acquisition and control signal output to meet the requirements of fast motion and high-performance machining.

Internal logic optimization ensures precise transmission of servo instructions.

Signal isolation and protection

Optoelectronic isolation between channels enhances system security and anti-interference capabilities.

Built in short-circuit and overcurrent protection functions to prevent damage to the driver or module.

Convenient status monitoring and maintenance

The LED status indicator light displays the operating status of the module and the status of channel signals.

Modular design facilitates on-site installation, debugging, and replacement.

Industrial environment adaptability

Anti vibration and anti impact design, suitable for machine tools and automated production environments.

EMC has strong anti-interference ability, ensuring stable operation of modules in complex industrial environments.

Product imag
