GIDINGS&LEWIS 501-03122-00 interface board

GIDINGS&LEWIS 501-03122-00 interface board

Product Details Introduction

Product Overview

The Giddings&Lewis 501-03122-00 interface board is a key module in the PiC series control system, used to achieve signal interface conversion between the controller and other devices or modules. It can receive signals from processors or input modules, convert them into electrical signals suitable for downstream devices, and also transmit signals from external devices to the control system, achieving data exchange and control instruction transmission.

Product Features

Multi channel signal interface

Provide multiple independent input/output channels, supporting simultaneous processing of multiple signals.

Capable of processing digital quantities, logical signals, and specific pulse signals.

High reliability design

Manufacturing industrial grade components to ensure long-term stable operation.

Anti vibration and anti impact design, suitable for industrial environments.

Signal isolation and protection

There is electrical isolation between channels to reduce the risk of interference and fault propagation.

Built in overcurrent and short-circuit protection to enhance system safety.

Status indication and convenient maintenance

The LED indicator light displays the signal status and the working condition of the interface board.

Modular design facilitates on-site installation, debugging, and replacement.

Compatibility and Scalability

Can seamlessly connect with PiC series controllers and input/output modules.

Support system expansion and can be used for medium to large-scale automation control systems.

Application field

Numerical Control Machine Tool: Connect sensors, encoders, and actuators to achieve machine tool motion and machining process control.

Automated production line: Implement signal interfaces between controllers and conveyor systems, sorting machinery, and assembly equipment.

Process control system: processes sensor signals and controls valves, pumps, and alarm devices.

Industrial equipment monitoring: Provide data acquisition and control interfaces to achieve equipment status monitoring and control.

Product imag
