AEG Modicon TSX3721100 processor module

AEG MODICON TSX3721100 processor module

Product Details Introduction

The AEG Modicon TSX3721100, as a modular base controller of the TSX Micro series, is equipped with an industrial grade core computing unit and is designed specifically for automation control scenarios of small and medium-sized OEM equipment. It has both stability and scalability.

Support 24VDC wide voltage power supply (suitable for 19.2-30V range), TSX3721100 has the ability to resist power supply micro interruptions up to<20ms, ensuring continuous operation in industrial scenarios without interruption.

The AEG Modicon TSX3721100 is equipped with 14Kwords RAM and 15Kwords Flash storage, which can be extended to 128Kwords program and data storage when paired with PCMCIA cards, meeting complex control logic requirements.

Equipped with 3 standard expansion slots, TSX3721100 can flexibly match digital, analog, and communication modules, supporting up to 256 point I/O expansion and adapting to diverse control needs.

The AEG Modicon TSX3721100 integrates 1 Uni Always and 1 Modbus RTU serial interface (19.2kbit/s) to achieve seamless data exchange with HMI and remote I/O.

The instruction execution efficiency is excellent, with Boolean instructions requiring only 0.13 μ s and floating-point operations requiring 4.5 μ s. The TSX3721100 ensures real-time response to control instructions and is suitable for high-speed automation scenarios.

The AEG Modicon TSX3721100 supports a multitasking architecture with 1 main task, 8 event tasks, and 1 fast task, efficiently handling parallel control requirements.

The working temperature covers 0-60 ℃, the storage temperature is -25-70 ℃, the humidity tolerance is 10-95% without condensation, and TSX3721100 is suitable for high and low temperature, high humidity industrial conditions.

The AEG Modicon TSX3721100 has a dual protection mechanism for overload and short circuit, complies with the IEC 61131-2 electromagnetic compatibility standard, and has anti-interference capability of Level 3.

Compatible with Unity Pro programming software, supporting multi language programming such as ladder diagrams and structured text, TSX3721100 reduces the threshold for debugging and secondary development.

The AEG Modicon TSX3721100 weighs approximately 1.72kg and is compact in size (reference 151 × 152 × 341.4mm). Its DIN rail installation design saves control cabinet space.

Supporting operation at altitudes up to 2000 meters, TSX3721100 is suitable for high-altitude industrial scenarios and has universality to cover deployment requirements in multiple geographical environments.

The AEG Modicon TSX3721100 has passed multiple international certifications and is compatible with the full range of TSX Micro expansion modules, seamlessly integrating into the existing automation ecosystem.

 AEG MODICON TSX3721100 Product imag

AEG MODICON TSX3721100 Controller Module
