Product Details Introduction

1. Adaptation scenarios and functions (X440-G2-48P-10)

Device positioning: ExtremeSwitching X440-G2 series fixed port switch, focusing on campus edge and enterprise access layer, suitable for high-density terminal access scenarios such as offices, teaching buildings, retail stores, etc. It can be directly deployed as an access switch or stacked expansion core node.

Port configuration: Equipped with 48 Gigabit PoE+RJ-45 ports (supporting 30W single port power supply) and 4 Gigabit SFP combo ports, Combo ports can flexibly switch between copper/fiber connections to meet the power and networking needs of IP cameras, wireless APs, VoIP phones, and other terminals.

Core function: Undertake dual responsibilities of terminal device access, data aggregation, and PoE power supply, support Summit Stack-V stacking technology (up to 8 devices stacked), and cooperate with ExtremeCloud IQ to achieve centralized management of the entire network, simplifying edge network deployment and operation.

2. Performance and Scalability (X440-G2-48P-10)

Forwarding performance: The switching capacity reaches 176Gbps, the packet forwarding rate is 130.9Mpps, and it adopts a non blocking line speed design to ensure that 48 ports can transmit at full speed without bottlenecks; The MAC address table supports 16000 entries and is suitable for multi terminal access scenarios.

PoE power supply: The total PoE power budget is 740W, with a maximum output of 30W per port. It can simultaneously power 48 low-power terminals (such as IP phones) or 24 high-power devices (such as high-definition cameras) without the need for additional power lines.

Flexible Expansion: Four Combo uplink ports support upgrading from 1Gbps to 10Gbps SFP+optical modules. Uplink speed can be increased through software authorization without the need to replace the entire machine, adapting to network bandwidth expansion needs.

3. Structure and Management Design (X440-G2-48P-10)

Physical specifications: 1U rack mounted design (4.4cm × 44.15cm × 36.86cm), weight 14.55lb (6.60kg), suitable for standard 19 inch cabinet installation, compact size saves data center space.

Management method: Supports triple management mode - ExtremeCloud IQ cloud platform (zero touch deployment, topology visualization), ExtremeCloud IQ Site Engine local management, Web GUI/CLI local configuration; Equipped with Console port, out of band management network port, and USB 2.0 interface, suitable for different operation and maintenance scenarios.

Easy to operate: The port is equipped with Link/ACT, Speed, and PoE status indicator lights, which intuitively display device connection, speed, and power status; Support firmware online upgrade and bulk configuration distribution, reducing maintenance costs.

Extreme Networks  X440-G2-48P-10 Product imag
