AMAT Applied Materials 0190-25423 DC Power Supply Module

AMAT Applied Materials 0190-25423 DC Power Supply Module

Product Details Introduction

1、 Product Overview

AMAT Applied Materials 0190-25423 DC Power Module is a high-performance DC power unit designed specifically for semiconductor manufacturing equipment.

It is used to provide stable DC power output for plasma power supplies, vacuum heating systems, gas control panels, and chamber controllers, and is one of the key energy conversion components in AMAT systems.

This module is usually installed in main power supply racks such as PVD (Physical Vapor Deposition), CVD (Chemical Vapor Deposition), Etch (Etch), etc. It has high stability, low ripple and complete electrical protection functions, ensuring high-precision current and voltage control in semiconductor processes.

2、 Technical parameters

Project parameter description

Product model 0190-25423

Product type: DC Power Supply Module

Input voltage AC 200-240 V, single-phase or three-phase, 50/60 Hz

Output voltage range DC 0-48 V (typical), adjustable

Output current range 0-20 A (depending on configuration)

Rated power 800-1000 W (typical value)

Voltage regulation rate ≤ 0.5%

Current regulation rate ≤ 1%

Output ripple and noise ≤ 50 mVp-p

Protection functions include overcurrent protection (OCP), overvoltage protection (OVP), over temperature protection (OTP), and short circuit protection

Cooling method: forced air cooling with internal cooling fan

Interface form: Backboard slot connection/Front end signal control interface

Indication and monitoring LED status display, voltage/current monitoring signal output

Working temperature: 0 ° C to 50 ° C

Typical size 3U modular rack size (approximately 130 × 220 × 350 mm)

Weight approximately 5-7 kg (including heat dissipation components)

AMAT Applied Materials 0190-25423  Product imag
