 Introduction

Edwards D155-04-000 gas leak detector, helium leak detection unit for semiconductor vacuum system.

Product Features:

1. Helium sniffing detection mode, quickly locate small leaks in pipelines and chambers

2. Fast detection response speed and sensitive feedback of leakage signals

3. Built in filtering components to block dust impurities and protect internal sensors

4. Dual sound and light alarm, intuitive prompt for leakage rate exceeding the standard

5. Support local parameter settings, customizable leak rate threshold

6. Equipped with data recording function to save historical leak detection data

7. Resist workshop electromagnetic interference and adapt to the on-site environment of semiconductor equipment

8. Can interface with PLC signals to achieve external interlocking monitoring

9. Modular sensing components, easy to replace and maintain on site

10. Compact body, can be installed in cabinets or moved on-site for use

Product Parameters:

1. Gas detection: helium gas

2. Detection mode: sniffing leak detection

3. Output: Sound and light alarm+switch signal output

4. Communication: Digital IO interface, supporting external interlocking

5. Applicable scenarios: Leak detection of vacuum chambers and pipeline welds

Edwards D155-04-000 is widely used in semiconductor vacuum piping and process chamber leak detection stations

Product imag
