NI PXIE-5663E Multifunctional I/O Module

NI PXIE-5663E Multifunctional I/O Module

Product Details Introduction

NI PXIe-5663E is a high-performance multifunctional I/O module designed specifically for the generation and analysis of radio frequency (RF) signals, suitable for various high-frequency applications. Here are some of its main features and application areas:

Main features:

Frequency range: Supports a frequency range of 10 MHz to 6.6 GHz, capable of covering a wide range of RF applications.

Instant bandwidth: Provides up to 50 MHz of instant bandwidth, capable of capturing and analyzing high-speed signals.

High resolution: Using a 16 bit resolution intermediate frequency (IF) digital module to achieve accurate signal measurement.

Modular design: PXIe-5663E combines RF signal down converter, digital module, and RF analog signal generator, which can be flexibly configured to meet various needs.

Application areas:

Wireless communication testing: widely used to test and verify the performance of wireless communication systems, including 5G, Wi Fi, and other modern communication technologies.

RF measurement: used for measuring RF signals, such as adjacent channel leakage ratio (ACLR), harmonic analysis, and spurious measurement.

Signal analysis: can be used for the analysis of complex RF signals, including modulation and demodulation, signal quality analysis, etc.

System integration: As a key module in the comprehensive testing system, it can collaborate with other devices to provide comprehensive testing solutions.

Technical specifications:

Input/output connection: Equipped with SMA female connector, supporting intermediate frequency (IF) input, clock input, and output signal connection.

Power requirements: A+3.3 VDC power supply is required, the power consumption of the RF signal down converter is 640 mA, the power consumption of the digital module is 1.75 A, and the power consumption of the analog signal generator is 1.00 A.

Working temperature range: 0 ° C to 55 ° C, suitable for common industrial environments.

Storage temperature range:- 40 ° C to 71 ° C ensures reliability under various harsh conditions.

In summary, NI PXIe-5663E is a powerful multifunctional I/O module widely used in various fields such as wireless communication, RF testing, signal analysis, etc., providing efficient and accurate solutions for modern RF applications.
