ProSoft 5205-DFNT-PDPS Ethernet Gateway

ProSoft 5205-DFNT-PDPS Ethernet Gateway

Product Details Introduction

ProSoft 5205-DFNT-PDPS Ethernet Gateway is an industrial communication module used for protocol conversion and data exchange between Ethernet/IP networks and PROFIBUS DP slave devices. This module is designed specifically for complex industrial automation systems and is suitable for integrated communication in multi protocol environments.

Product Overview

Model: 5205-DFNT-PDPS

Brand: ProSoft Technology

Function: As a gateway between Ethernet/IP protocol and PROFIBUS DP slave stations, it supports efficient and reliable data communication.

Key technical parameters

Parameter description

The Ethernet port supports 10/100 Mbps full duplex/half duplex Ethernet

The Ethernet protocol supports DF1 protocol, Ethernet/IP, and Modbus TCP

PROFIBUS communication supports PROFIBUS DP-V0 slave function

PROFIBUS speed range from 9.6 kbps to 12 Mbps

Supports up to 125 PROFIBUS slave devices

The data exchange capacity supports up to 244 bytes of input and 244 bytes of output

Configuration method through ProSoft Configuration Builder tool

Power requirement 24 V DC, maximum 3.5 W

Working temperature: 0 ° C to+60 ° C

Dimensions 13.97 x 10.16 x 4.32 cm

Protection level IP20

Product imag
