Product Details Introduction

PoE+and Gigabit Ethernet Fusion Configuration: Extreme Networks 220-12p-10GE2 is equipped with 12 10/100/1000Base-T PoE+ports, compatible with IEEE 802.3at standard, with a maximum power supply of 30W per port and a total PoE power budget of 123W. It can efficiently drive terminal devices such as IP cameras and wireless APs.

10GE high-speed fiber optic uplink capability: equipped with 2 10GBase-X SFP+optical ports, supporting 10Gbps high-speed data transmission, with a bandwidth increase of 10 times compared to gigabit uplink models, which can meet the high bandwidth interconnection needs of enterprise branches and core networks.

High performance line speed forwarding architecture: 220-12p-10GE2 provides 64Gbps switching capacity and 47.6Mpps forwarding rate. All ports support non blocking line speed processing, ensuring bottleneck free transmission for gigabit terminal access and 10G uplink.

L2/L3 multi-layer routing function: As a converged switch, it not only has complete layer 2 characteristics, but also supports static routing (up to 64 routing entries) and RIP dynamic routing protocol, which can achieve complex network segmentation and cross segment communication.

Multi dimensional convenient management system: supports centralized control of the ExtremeCloud IQ cloud platform, web visualization configuration, as well as serial port console and CLI command line management. It is also equipped with a 10/100Base-T out of band management port to adapt to different operation and maintenance scenarios.

Stereoscopic security protection mechanism: Built in access control list (ACL), which can accurately control traffic based on ports and IP addresses, supports IEEE 802.1x authentication and broadcast storm suppression functions, effectively preventing network attacks and unauthorized access.

Silent and compact deployment design: Adopting a 1U rack structure, the size is only 1.69 "× 8.23" × 10.05 ", and supports fanless operation mode, with no noise interference during operation, suitable for deployment in quiet environments such as offices and open office areas

Stable and reliable hardware foundation: equipped with high-performance processors and sufficient memory configuration, supporting 16000 MAC address table storage, built-in 100-240V wide AC power supply, able to adapt to different voltage environments in different regions, ensuring continuous and stable operation of the equipment.

Flexible stacking and expansion capability: Supports stacking up to 4 devices, achieving centralized management of a single IP address, simplifying the operation and maintenance process of multiple devices. At the same time, SFP+optical ports are compatible with different wavelength fiber modules, meeting long-distance transmission needs.

Rich protocol compatibility features: Fully supports IEEE 802.1q VLAN, 802.3ad link aggregation, STP/RSTP spanning tree and other protocols, compatible with LLDP, SNMP and other management protocols, and can seamlessly integrate into existing enterprise network architectures.

Extreme Networks 220-12p-10GE2 Product imag
