Extreme Networks 220-12p-10GE2 Port Switch

Extreme Networks  220-12p-10GE2 Port Switch

Product Details Introduction

PoE+and high-speed port combination: Extreme Networks 220-12p-10GE2 is equipped with 12 10/100/1000Base-T PoE+ports, compatible with IEEE 802.3at standard. With a total power of 123W, it can accurately power wireless APs, high-definition cameras, and other devices, while retaining 2 10G Base-X SFP+empty ports to support 10G expansion.

10Gbps fiber optic uplink capability: The switch's 2 SFP+ports support 10Gbps fiber optic connections, which increases bandwidth by 10 times compared to gigabit uplink solutions. It can easily connect to core networks and adapt to high-speed transmission scenarios such as enterprise high-definition video conferencing and big data backup.

Efficient line speed forwarding performance: The 220-12p-10GE2 achieves full port line speed processing with a 64 Gbps switching capacity and 47.6 Mpps forwarding rate. Based on a non blocking architecture design, it ensures zero latency for gigabit access and 10 gigabit uplink data transmission.

Layer 2 and 3 dynamic routing features: As a manageable switch, it not only has a complete set of layer 2 functions, but also supports IPv4 RIP dynamic routing and 64 static routing, which is more suitable for the dynamic network topology requirements of branch offices compared to static routing solutions.

Multi mode intelligent management system: supports unified control of the ExtremeCloud IQ cloud platform, with web GUI, centralized management center, and standard CLI. It also supports stacking of 4 devices and single IP management, greatly simplifying the difficulty of medium-sized network operation and maintenance.

Layered security protection mechanism: Built in 100 sets of ACL access control lists (each containing 1023 rules), capable of multi-dimensional filtering of traffic based on IP, MAC, and port, combined with 802.1X authentication and DHCP listening, to build a three-dimensional security defense line.

Intelligent Service Quality Scheduling: Equipped with an 8-level traffic queue and IEEE 802.1p priority mapping, it can automatically identify key traffic such as VoIP and video conferencing and allocate bandwidth, ensuring business continuity through traffic shaping technology.

Low noise and energy-saving deployment design: adopting intelligent temperature controlled fans, the fan can stop running in an environment of 0-35 ℃, and the noise tends to be zero. The 1.88kg lightweight body is matched with a 1U height, suitable for wall mounted or rack deployment in quiet scenarios such as offices and conference rooms.

Reliable hardware redundancy support: Supports RPS-500P redundant power module expansion, with limited lifetime warranty and next day hardware replacement service, further reducing equipment downtime risk and ensuring core business continuity compared to fixed power supply design.

Adaptation optimization for small and medium-sized enterprises: As an economical 10 Gigabit expansion switch, its combination of PoE+power supply, 10 Gigabit uplink and stacking functions perfectly matches the high-density access and high-speed interconnection needs of enterprise branches, chain stores and other scenarios.

Extreme Networks 220-12p-10GE2 Product imag
