AMAT Applied Materials 3870-02612 Valve Components

AMAT Applied Materials 3870-02612 Valve Components

Product Details Introduction

1. Control and Sealing Performance (AMAT 3870-02612)

Adopting an electromagnetic pilot structure, supporting on-off switching of liquid/gas media, response time ≤ 10ms, suitable for precise control of semiconductor process fluids

Diaphragm seal design (NBR/EPDM material optional), leakage rate ≤ 0.1ml/min, in compliance with ISO 5208 sealing standard

2. Adaptation and linkage (AMAT 3870-02612)

Nominal pressure 0.03~1.6MPa, optional diameter 15~50mm, suitable for reaction chamber gas/liquid pipeline system

Equipped with a signal feedback interface, it can be connected to the AMAT 0100-09008 pneumatic control board to achieve real-time feedback of switch status

3. Structure and Environment (AMAT 3870-02612)

Brass/stainless steel valve body, optional internal thread/flange connection, compact size suitable for equipment dense pipeline layout

Working temperature -5~80 ℃, protection level IP54, anti vibration and impact, suitable for harsh working conditions in clean workshops

4. Reliability (AMAT 3870-02612)

The core components have undergone 10 million cycles of testing, with MTBF ≥ 100000 hours and support for 7 × 24-hour continuous operation

Compliant with API 598/ASME B16.34 standards, UL/CE certification, original factory warranty of 1-3 years, and quick replacement of spare parts

AMAT Applied Materials 3870-02612 Product imag
