Product Details Introduction

Product Overview

Control Techniques UNI1401 is a low-power alternating current (AC) variable speed drive belonging to the UniDrive series. It is used to control the speed and torque of small three-phase asynchronous motors, achieving smooth start-up, energy-saving operation, and equipment protection. UNI1401 is designed to be compact and easy to operate, suitable for applications such as light industry automation equipment, fans, pumps, and experimental benches.

Technical Specifications

Model: UNI1401

Type: AC Drive/VFD

Motor type: Three phase asynchronous motor

Rated power: approximately 1 kW (specific configuration according to model)

Input power supply: single-phase 200-240 V AC or three-phase 200-240 V AC

Output voltage/frequency: adjustable, supports variable frequency speed regulation

Control method:

V/F (voltage/frequency) control

Basic vector control (supported by some models)

Protection functions: overload, overvoltage, undervoltage, short circuit, overheating protection

Communication interface: Some models support digital/analog interfaces

Installation method: wall mounted or cabinet mounted, modular design

Application scenarios

Light industrial equipment: small conveyor belts, mixers, packaging equipment

HVAC system: energy-saving speed regulation of fans, water pumps, and air conditioning systems

Experiment and R&D: Motor testing platform and R&D experimental equipment

Small scale automated production line: low-power equipment for light industry, textile, food processing, etc

Energy Management: Precise Control of Small Pump and Fan Systems

Control Techniques  UNI1401 Variable Speed Drive Product imag
