Control Techniques SP2401 Servo Drive

Control Techniques SP2401 Servo Drive

Product Details Introduction

Product Overview

Control Techniques SP2401 is an industrial grade servo drive belonging to the Unidrive SP series. This driver is designed specifically for closed-loop servo motors, providing precise speed, torque, and position control. SP2401 is suitable for high-performance automation equipment, machine tools, packaging machinery, and robot systems, ensuring smooth motion control, fast response, and accurate positioning.

Technical Specifications

Model: SP2401

Type: Servo Drive/AC Servo Drive

Suitable motor: three-phase servo motor

Rated power: approximately 2.4 kW (may vary slightly depending on the specific model configuration)

Input power supply: three-phase 380-480 V AC

Control method:

Closed-loop vector control

Accurate position, speed, and torque control

Feedback interface: Supports encoders (incremental/absolute)

Protection functions: overload, overvoltage, undervoltage, short circuit, over temperature protection

Communication interface: Supports industrial protocols such as Modbus, CANopen, Ethernet/IP, etc

Installation method: Modular design, can be installed in cabinets or racks

Application scenarios

High precision machine tools: CNC machine tool spindle or servo axis drive

Industrial Robots: Joint and Handling Motion Control

Packaging Machinery: High speed Packaging Machines and Sorting Equipment

Textile and printing equipment: production equipment that requires precise motion control

Experiment and R&D: Servo motion control testing and experimental platform

Control Techniques  SP2401 Servo Drive Product imag
