Control Techniques SX33200300PB AC Drive

Control Techniques SX33200300PB AC Drive

Product Details Introduction

Product Overview

Control Techniques SX33200300PB is an industrial grade AC motor drive belonging to the Unidrive SP/SX series. This driver is used to control the speed, torque, and direction of AC motors, achieving precise process control and equipment protection. Modular design and rich interfaces make it suitable for high-performance drive control of automated production lines, pumps, fans, conveyors, and other industrial equipment.

Technical Specifications

Model: SX33200300PB

Type: AC Drive/VFD

Motor type: Three phase asynchronous motor

Rated power: approximately 30 kW (specific configuration according to model)

Input power supply: three-phase 380-480 V AC

Output voltage/frequency: adjustable, supports variable frequency control, achieves motor speed regulation

Control method:

V/F (voltage/frequency) control

Vector control (open-loop/closed-loop)

Protection functions: overload, overvoltage, undervoltage, short circuit, overheating protection

Communication interface: Supports industrial protocols such as Modbus, CANopen, Ethernet/IP, etc

Installation method: cabinet installation or panel installation, modular design, supporting heat dissipation and maintenance optimization

Application scenarios

Industrial automation production line: controlling equipment such as conveyor belts, mixers, packaging machines, etc

Pump and fan system: achieve precise adjustment of flow rate, pressure, and air volume, saving energy and reducing consumption

Metallurgical and mining equipment: load control and protection of large machinery and motors

Machine tools and processing equipment: precise control of motor speed and torque to achieve high-precision processes

Building and Energy Management: Motor Drives for HVAC Systems, Generator Sets, and Water Treatment Equipment

Control Techniques SX33200300PB AC Drive Product imag
