AEG Modicon AS-B884-002 Programmable Controller

AEG MODICON AS-B884-002 Programmable Controller

Product Details Introduction

The AEG Modicon AS-B884-002, as a signature programmable controller of the Micro84 series, is designed with the core concept of "high integration+flexible adaptation". It is specifically designed for small and medium-sized automation equipment and distributed control scenarios, with a streamlined structure and industrial grade reliability. It has become the preferred core for single machine control of equipment and decentralized control of production lines.

Core performance focuses on practicality and efficiency: equipped with a dedicated industrial grade microprocessor, the logic operation speed reaches 0.12 μ s/Boolean instruction, supporting a maximum of 8kByte of user program memory and 4kByte of data memory, which can smoothly run logic control, sequence control, and simple process control tasks. Innovation supports host simulation programming function, which can directly modify PC state logic, simplify debugging process, and adapt to rapid iteration production process requirements. Compatible with the Modbus serial communication protocol, which is an industrial standard bus, it can seamlessly interface with sensors, actuators, HMI touch screens, and upper computer systems to achieve real-time data exchange and precise command issuance, ensuring the stability and universality of the control link.

The integrated scalability highlights the flexibility advantage: adopting an integrated compact design, the body integrates digital I/O channels (standard 16 input/16 output), supports direct driving of small actuators, and can meet basic control needs without the need for additional expansion modules. At the same time, reserved expansion interfaces are available, compatible with Modicon's full range of I/O modules (including analog and special function modules), supporting up to 4 cascaded expansion modules, with a maximum of 256 I/O expansion points, flexibly adapting to control scales from single machine devices to small production lines. Equipped with RS-485 serial communication interface, the transmission rate can be parameterized and adjusted between 110Bit/s-38400Bit/s, with a built-in 2kByte data buffer to ensure stable long-distance data transmission without loss.

Comprehensive and balanced adaptability to industrial scenarios: adopting a 24V DC wide voltage power supply design, with a working temperature range of -10 ℃ -60 ℃ and a relative humidity tolerance of 5% -95% (non condensing), it has good electromagnetic interference resistance and meets the EN 61000 electromagnetic compatibility standard. It can adapt to conventional industrial environments such as workshop dust and vibration. The protection level reaches IP20, with built-in triple hardware protection for overvoltage, overcurrent, and short circuit, combined with software watchdog function, effectively avoiding equipment failures caused by power supply abnormalities and program runaway. The installation method supports quick installation of 35mm DIN rails, with a compact body design (only half the size of a standard PLC), greatly saving control cabinet installation space and adapting to equipment intensive layout scenarios.

AEG MODICON AS-B884-002 Product imag

AEG MODICON AS-B884-002 Controller Module
