TRICONEX 8312 power module

 TRICONEX  8312 power module

Product Details Introduction

Dual isolation redundant power supply: adopting a dual isolation power supply design, the two power supplies can automatically switch, and the failure of one power supply does not affect the system power supply. Combined with power filtering function, it can resist voltage fluctuations and ensure continuous and stable power supply.

Wide voltage input adaptation: Supports 220-380V wide range AC input without the need for additional transformers, and can adapt to different industrial power grid specifications such as power plants and chemical plants, reducing power supply adaptation costs.

Triple redundancy ensures safety: using the iconic TMR architecture of TRICONEX, three independent circuits are synchronously powered and mutually calibrated, and a single circuit fault is automatically shielded, in compliance with IEC 61508 safety standards, ensuring uninterrupted power supply in high-risk scenarios.

Comprehensive protection against damage: Equipped with overload, over temperature, and short circuit protection, the output current can adapt to various specifications from 550A to 3500A. When the load is abnormal, the power can be quickly cut off to avoid module and backend equipment burning out.

Low consumption and energy-saving operation: The overall power consumption of the machine is ≤ 20W, which is 30% lower than that of ordinary power modules. It also supports light load adaptive frequency reduction, and long-term operation can significantly reduce industrial electricity costs, making it suitable for intrinsically safe power supply application scenarios.

Support online maintenance: It can be equipped with electric hot plugging, and modules can be replaced or repaired during system operation without stopping the line. It is particularly suitable for continuous production scenarios such as petroleum and chemical industries, improving equipment utilization.

Intelligent status diagnosis: Real time display of power supply status and fault information through LED indicator lights, combined with system logging to record power abnormalities, can quickly locate overload, overvoltage and other issues, reducing troubleshooting time.

Strong adaptability to industrial environment: The working temperature covers -20 ℃ to 50 ℃, and the circuit board is treated with moisture-proof measures, which can adapt to high humidity environments of 10% to 90% RH. It can also operate stably in dusty steel plants and power plants.

Precise integration with safety system: seamlessly adapted to the TRICONEX TMR safety control system, it can directly supply power to I/O modules and communication modules, without the need to adjust parameters after insertion, and quickly establish power links.

High durability and long lifespan: The casing is made of corrosion-resistant materials, and key components are selected from industrial grade chips. It supports non-destructive transmission and has an average fault free working time of over 100000 hours, making it suitable for long-term continuous operation scenarios.

 TRICONEX 8312 Product imag
