ENTERASYS SK8009-1224-F8 Switch

Extreme Networks  SK8009-1224-F8 Switch

Product Details Introduction

Mixed port density configuration: The ENTERASYS SK8009-1224-F8 switch is equipped with 24 10/100/1000Base-T copper cable ports and 8 1000Base-X SFP optical ports, while providing 2 10GbE SFP+upstream ports. The total bandwidth of the ports reaches 68Gbps, and the switching capacity is up to 136Gbps, which can meet the dual needs of small and medium-sized enterprise core layer aggregation and high-density access.

Full Gigabit PoE Power Supply Capability: This switch supports the IEEE 802.3af/at PoE standard, with 24 copper ports equipped with PoE power supply. The total PoE power budget is 370W, with a maximum output of 30W per port. It can directly power IP cameras, Wi Fi 6 wireless APs, IP phones, and other terminals, reducing additional power wiring costs.

Multi layer network redundancy guarantee: SK8009-1224-F8 has built-in IEEE 802.1d STP, 802.1w RSTP, and 802.1s MSTP spanning tree protocols, supports 802.3ad LACP link aggregation (up to 8 ports per group, can configure 16 aggregation groups), and works with VRRP virtual routing redundancy protocol to achieve dual redundancy of links and routes, ensuring zero interruption of business.

Comprehensive security protection system: integrating 802.1X port authentication, MAC address binding (up to 512 MACs can be bound to a single port), and dynamic ARP detection functions, which can effectively prevent illegal access and ARP spoofing attacks; Simultaneously supporting L2-L4 layer ACL access control, accurately controlling traffic based on dimensions such as port, IP address, and port number, and building a three-dimensional security barrier.

Intelligent traffic control capability: Supports 802.1p priority tagging and DSCP traffic classification, with 8 priority queues per port, using a mixed scheduling algorithm of WRR (weighted polling) and SP (strict priority) to ensure priority transmission of critical services such as voice and video, avoiding service degradation caused by congestion.

Efficient operation and maintenance management support: compatible with Web GUI graphical management and CLI command line management, supports SNMP v1/v2 c/v3 protocols, can be integrated with Enterasys NetSight management platform for centralized monitoring and configuration; At the same time, it has port mirroring (supporting many to one and one to one modes) and cable detection functions to quickly locate faulty nodes and reduce the difficulty of operation and maintenance.

Multicast optimization processing capability: Supports IGMP v1/v2/v3 snooping and MLD snooping protocols, can manage up to 1024 multicast groups, and with multicast fast departure and multicast filtering functions, accurately pushes multicast streams such as video conferences and IPTV, avoiding bandwidth waste and improving network resource utilization.

 Extreme Networks SK8009-1224-F8 Product imag
