Extreme AN01463 Port Switch

Extreme Networks AN01463 Port Switch

Product Details Introduction

1、 Core parameter reference (based on brand universal characteristics)

Model attribute: It is speculated to be an entry-level or mid-range managed/unmanaged switch under Extreme Networks. "AN01463" may be the product sequence code, and "port switch" indicates that it is an access layer device. The common form is 1U rack mounted, targeting small and medium-sized network access needs.

Port configuration (speculation): If it is a 24 port model, it may include 24 10/100/1000Base TX electrical ports and 2-4 SFP optical ports (upstream); If it is a 48 port model, the number of ports will double, and some versions may support PoE power supply (depending on the actual model).

Key performance (speculation): The switching capacity is usually 32-128Gbps, the packet forwarding rate is 10-96Mpps, it supports rate adaptation and full duplex mode, and is suitable for concurrent communication of small and medium-sized terminals.

2、 Core functions and values (based on brand commonalities)

Basic networking capability: Provides high-density port access, supports VLAN partitioning and port isolation, reduces network broadcast storms, and improves transmission efficiency.

Management feature: If it is a hosted model, it supports web UI and CLI management; Unmanaged models are plug and play, suitable for scenarios without professional operation and maintenance, and some support simple SNMP monitoring.

Security and reliability: Built in basic protection functions such as MAC address filtering and port security, supporting link aggregation (for some models) to ensure connection stability.

3、 Typical Usage Reference

Small office network: connects terminals such as PCs, printers, IP phones, etc. as access layer devices to the core router or switch.

Retail and catering scenarios: deployed in stores, connected to cash register devices and surveillance cameras, non custodial models can reduce deployment difficulty.

Branch networking: adapted to small and medium-sized branch offices, achieving high-speed data exchange with headquarters through optical port uplink.

Extreme Networks AN01463  Product imag
