AMAT Applied Materials 3870-02656 Valve Locking Component

AMAT Applied Materials 3870-02656 Valve Locking Component

Product Details Introduction

1、 Product Overview

The AMAT 3870-02656 valve locking component is a fluid control and safety protection component used by Applied Materials in its semiconductor equipment. This component is mainly used in gas or vacuum systems to lock, switch, or safely isolate fluid channels.

Its' Lockout 'function means that the valve can be mechanically locked in a specific state to prevent accidental operation or unauthorized activation, which is commonly used in equipment maintenance, upkeep, or process safety protection.

2、 Structure and Technical Characteristics

Three way design (3-way)

It has three fluid channels that can be used for switching and distributing gas or vacuum flow.

Commonly used to quickly switch pipelines between "working state" and "maintenance state".

Barb Straight hose interface

The interface type is a straight through hose connector (Barb type), which facilitates quick insertion of hoses.

No additional threads or flange connections are required, making it easy to maintain and replace.

Mechanical locking structure

A mechanism with a built-in mechanical lock or insertable lock pin that allows the valve to be locked in either the "open" or "closed" position.

Prevent accidental opening in high-pressure or hazardous gas environments.

High cleanliness material design

The valve body is usually made of stainless steel or high-strength alloy material, which has corrosion resistance and oxidation resistance.

The sealing components may use Viton or other high-purity sealing materials to ensure no contamination in semiconductor process gases.

Pressure resistance and vacuum compatibility

Suitable for vacuum systems or medium low pressure gas delivery systems.

Ensure no leakage during vacuum pumping or gas pressurization.

High reliability structure

Semiconductor equipment suitable for long-term operation, with high cycle life and excellent sealing retention capability.

Compact structure, light weight, easy to install in limited space.

Modular installation form

It can be integrated as an independent unit into AMAT's gas distribution system, valve island, or safety isolation module.

Standardized design facilitates quick replacement and maintenance.

AMAT Applied Materials 3870-02656 Product imag
