Product Details Introduction

Product Overview

AMAT DIP-360-002 is an analog signal processing printed circuit board (Analog PCB Board) in Applied Materials semiconductor equipment.

This board is mainly used for the acquisition, processing, and amplification of analog signals, providing reliable analog signal interfaces for internal sensors, actuators, or control systems of the equipment. It is one of the key signal processing modules in semiconductor process equipment.

Technical parameters (inferred based on AMAT simulation of PCB board characteristics)

Type: Analog Signal PCB/Analog Interface Board.

Function:

Receive weak analog signals (such as voltage, current, or resistance signals) output by sensors.

Amplify, filter, isolate, or linearize signals.

Transfer the processed signal to the controller or data acquisition system.

Onboard components: operational amplifiers, filters, connectors, resistors, capacitors, etc.

Interface type: Analog input/output interface, some models may have digital control interfaces.

Installation location: In the equipment control cabinet or module slot, near the sensor or control module for installation.

Features: High precision, high linearity, low noise, suitable for clean and vibration environments of semiconductor equipment.

Application scenarios

sensor signal processing

Adjust and amplify analog signals such as pressure sensors, temperature sensors, and flow sensors.

Process closed-loop control

Transmit analog signals to the controller to achieve closed-loop regulation of process parameters such as pressure, temperature, and flow rate.

SCADA

Support the device monitoring system to obtain high-precision simulation data, achieve process data recording and analysis.

Maintenance and module replacement

Modular PCB design facilitates quick replacement or upgrade, reducing equipment downtime.
