Motorola V452-B 68040 Input/Output Module

Motorola  V452-B 68040 Input/Output Module

Product Details Introduction

Product Overview

Motorola V452-B is an input/output (I/O) module based on the Motorola 68040 processor architecture, typically used in VME bus systems or embedded control platforms. It integrates digital and analog I/O functions, enabling signal acquisition and control of industrial equipment, sensors, and actuators, suitable for industrial automation, testing and measurement, and embedded system applications.

Technical parameters (typical features)

Processor: Motorola 68040 series

Bus interface: VMEbus standard interface, compatible with A16/A24/A32 address mode, D08/D16/D32 data transmission

Input/output type:

Digital input/output: Supports TTL/CMOS compatible signals

Analog input/output (some models): supports voltage or current signal interfaces

Storage and buffering: onboard RAM or FIFO is used for data caching to reduce the load on the main CPU

Interface Expansion: Supports peripheral connections such as serial and parallel ports

Power supply: Powered by VME backplane (+5V/± 12V)

Work environment: Industrial grade design, supporting continuous operation and anti-interference capability

Application scenarios

Industrial automation: as an I/O interface module for PLC or motion control systems

Testing and Measurement System: Collecting Sensor Data, Controlling Experimental Equipment

Traffic Control: Data Collection and Control of Railway and Subway Signal Systems

Embedded Control Platform: Combined with MVME series CPU modules, achieve complete embedded system control

Telecommunications equipment: Implementing logic and signal control within switches or base stations

Motorola V452-B 68040 Input/Output Module Product imag
