GIDINGS&LEWIS 502-02748-06 Valve Drive Board

GIDINGS&LEWIS 502-02748-06 Valve Drive Board

Product Details Introduction

GIDINGS&LEWIS 502-02748-06 Valve Drive Board

Product Overview

Giddings&Lewis 502-02748-06 valve drive board is an execution control module used in CNC machine tools or automation systems, mainly for controlling the opening and adjustment of hydraulic or pneumatic valves. It receives instructions from the control system or CPU board, converts digital signals into control signals that can drive valves, thereby achieving hydraulic/pneumatic actuator actions in machine tools or equipment.

Technical Features

Valve control: supports the driving and adjustment of various hydraulic or pneumatic valves.

Digital signal interface: Receive instructions from the control system to achieve precise action control.

Modular design: can be directly installed in the rack or control cabinet for easy replacement and maintenance.

Industrial grade reliability: anti-interference, vibration resistance, suitable for machine tools and industrial automation environments.

Protection function: It has overload and short circuit protection to improve system safety.

Application field

CNC boring and milling machine hydraulic system

Control hydraulic or pneumatic actions such as worktable lifting, tool holder movement, and fixture clamping.

Vertical lathe and composite machining center

Manage hydraulic fixtures, tool adjustment mechanisms, and other execution units to achieve precise control of machining actions.

Automatic production line

Drive hydraulic or pneumatic actuators on the production line to achieve actions such as material handling, clamping, sorting, etc.

Machine tool transformation and upgrading

Interface upgrade for hydraulic or pneumatic system control in the numerical control transformation of old equipment.

Testing and Maintenance

Used for valve action testing and debugging to ensure reliable operation of hydraulic/pneumatic systems.

Product imag
