Motorola MVME162-522A is a control pulse card with VMEbus architecture, belonging to the expansion module of MVME162 series single board computers. It is mainly used for pulse control, motion control, and real-time signal generation, and can work in conjunction with MVME series CPU modules to provide accurate pulse output and control capabilities for industrial automation, machine tool control, and testing measurement systems.

This module is connected to the CPU and other I/O modules through the VME bus, achieving multi-channel pulse control, synchronous counting, and timing management. It is an ideal component for high-precision control in industrial and scientific research scenarios.

Technical Specifications

Bus interface: VMEbus standard, bus width 16/32 bits, supports A16/A24/A32 address space

Functional positioning:

Multi channel pulse output

Counter/Timer Function

Pulse synchronization and cycle control

Number of channels: Typical 4-8 independent pulse channels (specific models can be configured)

Control accuracy: microsecond level pulse control, supporting high-speed real-time computation

Electrical characteristics: Industrial grade isolation, anti-interference design

Compatibility: Compatible with Motorola MVME162 series CPU modules, capable of running RTOS such as VxWorks and pSOS

Working environment: Industrial temperature range, suitable for long-term high load operation

Application scenarios

Industrial Automation and Machine Tool Control

Control servo drivers and stepper motors to achieve precise position and speed adjustment.

Robots and Motion Control Systems

Multi axis control and synchronous motion management, supporting high-speed closed-loop control.

Research and Testing System

Used for pulse generation, counting, and synchronization control of experimental equipment.

Process control and automation equipment

Provide precise time and pulse signals in assembly lines or automated equipment.

Communications and Signal Processing

Generate and manage time sensitive synchronization signals.

Motorola MVME162-522A Control Pulse Card Product imag
