Motorola MVME 01-W3508F Expansion Board

Motorola MVME 01-W3508F Expansion Board

Product Details Introduction

Product Overview

The Motorola MVME 01-W3508F expansion board is a functional expansion module based on the VMEbus architecture, mainly used to provide additional I/O interfaces, signal processing capabilities, and system function expansion for single board computers or controllers. It is often used as a supporting unit for the core control module in embedded control systems, enhancing the overall flexibility, scalability, and application coverage of the system.

Technical Features

Standard architecture: Compliant with VMEbus design, supports multi board system interconnection

Interface Expansion: Provides additional I/O channels and supports external device connections

Signal processing: capable of data acquisition and signal adaptation, capable of achieving level matching and isolation

Modular design: can be flexibly configured and used in combination with main control boards (such as MVME-121, MVME-162, etc.)

High reliability: using industrial grade PCB technology, supporting long-term stable operation

System compatibility: Supports compatibility with multiple Motorola embedded controllers, compatible with mainstream real-time operating systems (VxWorks, OS-9, etc.)

Application field

Industrial Automation

Expansion of peripherals for automated production lines

Signal interface between robots and motion control

Real time data collection and monitoring in factories

Electricity and Energy

Remote I/O expansion module for power station

Signal acquisition and control of power transmission and distribution network

External interface for energy dispatch and monitoring equipment

Traffic and Transportation

Railway/subway signal system expansion unit

Interface between sensors and actuators of intelligent transportation devices

Embedded expansion modules for transportation vehicles such as airplanes and ships

Defense and Aerospace

Signal Expansion of Military Communication and Combat Command System

Peripheral interface between radar and fire control equipment

Multi channel data acquisition for aerospace measurement and control system

Communications and Networking

Expansion of Telecommunications Switches and Network Equipment Interfaces

Satellite communication system signal adaptation

Auxiliary module for data transmission and protocol processing

Research and Medical

Interface expansion of high-energy physics experimental equipment

Data acquisition unit for medical imaging and monitoring equipment

Laboratory automation and multi-channel monitoring

Motorola  MVME 01-W3508F Expansion Board  Product imag
