GIDINGS&LEWIS 501-04715-01 servo control board

GIDINGS&LEWIS 501-04715-01 servo control board

Product Details Introduction

GIDINGS&LEWIS 501-04715-01 servo control board

Product Overview

Giddings&Lewis 501-04715-01 servo control board is a core control module used for CNC machine tools and automation equipment, mainly responsible for processing and controlling the drive and feedback signals of servo motors. It undertakes the core function of motion control in the CNC system, converting CNC instructions into precise control signals for servo drives and motors, thereby achieving high-speed and high-precision machine tool motion.

Technical Features

High precision motion control: achieving precise adjustment of position, velocity, and acceleration.

Closed loop control: supports real-time processing of feedback signals such as encoders and rotary transformers to ensure stable operation of the servo system.

Multi axis coordination: can control multiple servo axes simultaneously, suitable for complex linkage machining.

Real time response: With low latency control performance, it meets the requirements of high-speed machining.

Industrial grade design: Strong anti-interference performance, suitable for heavy-duty machine tool environments.

Application field

CNC boring and milling machines

Control the spindle and feed servo system to achieve high-precision cutting and large workpiece machining.

Vertical lathe, milling and turning composite machine tool

Coordinate the linkage control of multiple servo axes, supporting complex surface machining and multi process machining.

Automatic production line

Manage the servo actions of the execution unit to ensure synchronization and efficient operation between devices.

Robots and robotic arms

Provide precise motion control, suitable for automated operations that require high dynamic response.

Machine tool transformation and upgrading

In the CNC upgrade of old equipment, as the core module of servo control, it improves the accuracy and efficiency of machine tools.

Product imag
