GIDDINGS&LEWIS 401-30234-01 Stepper Motor

1、 Product Overview

GIDINGS&LEWIS 401-30234-01 is an industrial grade stepper motor used for precise angle and displacement control. This motor can achieve high-precision positioning without closed-loop feedback and is often used in conjunction with stepper drivers. It is widely used in CNC machine tools, automated production lines, robot systems, and other high-precision position control scenarios. The stepper motor has a simple structure and high reliability, suitable for repeated positioning and slow high-precision control.

2、 Technical parameters (typical indicators, actual subject to physical object)

Motor type: Two phase or three-phase stepper motor

Rated voltage: DC 24V -48V (depending on configuration)

Step angle: 1.8 ° or 0.9 ° (customizable)

Rated current: 1-5A (depending on model)

Maintain torque: 0.5-3 N · m (according to specifications)

Inertia: Low inertia design, suitable for quick start/stop

Installation method: flange installation, standard rack interface

Working environment: industrial grade temperature, anti vibration, anti-interference

Cooling method: natural air cooling or fan assisted

3、 Application scenarios

CNC machine tool

Control the precise movement of the feed axis, tool, or worktable to achieve repeated positioning and micro step interpolation.

Automatic production line

Drive the conveying device, assembly platform or feeding mechanism to achieve high-precision action and process control.

robot system

Used for precise angle control of joints or actuators, ensuring repeat positioning accuracy.

Printing and packaging equipment

Control winding, tension, feeding, and positioning actions to achieve stable processing and packaging.

Experimental and testing platform

Precision positioning platform, microscope stage, experimental stage moving device, etc.

Product imag
