GIDDINGS&LEWIS 502-03786-00 Input Encoder Module

1、 Product Overview

GIDDINGS&LEWIS 502-03786-00 Input Encoder Module is a position/velocity feedback input module for industrial control systems, used to read signals from rotary or linear encoders and convert them into data recognizable by the control system. This module provides precise motion feedback for machine tools, automated production lines, and robot systems, supports closed-loop control and high-precision positioning, and is an important component for achieving multi axis synchronous control and high-speed motion control.

2、 Technical parameters (typical indicators, specific subject to physical object)

Module type: Encoder input module

Number of channels: Multi channel input (typical 4-8 channels)

Supporting encoder types: incremental encoder, absolute value encoder

Input signal level: TTL/HTL (depending on encoder type)

Resolution: Depending on the encoder body, it can reach up to 25000-50000 PPR

Sampling speed: High speed sampling to meet real-time control requirements

Isolation method: photoelectric isolation, enhancing anti-interference ability

Interface method: Modular slot design, compatible with GIDDINGS&LEWIS 502 series control bus

Status indication: LED displays channel status and error signals

3、 Application scenarios

CNC machine tool

Receive encoder signals from the spindle and feed axis to achieve high-precision closed-loop motion control.

Automatic production line

Real time feedback on the movement position of conveyor belts, robotic arms, or assembly mechanisms.

robot system

Obtain joint angle and position data to ensure multi joint motion coordination and repeat positioning accuracy.

Printing and packaging machinery

Accurately collect speed and position information during winding, tension, and alignment processes.

Testing and Inspection Platform

Provide high-speed and accurate position feedback signals for precision motion platforms or experimental devices.
