GIDINGS&LEWIS 502-03898-50 DC output board

GIDINGS&LEWIS 502-03898-50 DC output board

Product Details Introduction

Product Overview

Giddings&Lewis 502-03898-50 is a DC output board in the PiC series control system, used to convert the logic signals of the controller into electrical signals that can drive DC loads. This module is used in CNC machine tools and automation equipment to control relays, solenoid valves, indicator lights, or other DC actuators, achieving the interface between the control system and mechanical actions.

Product Features

Multi channel DC output

Provide multiple independent output channels to simultaneously control multiple DC loads.

Electrical isolation between channels reduces the risk of interference and fault propagation.

High reliability and protection function

Built in overcurrent and short-circuit protection to prevent module and load damage.

Industrial grade design, resistant to vibration and impact, suitable for complex working environments.

Status indication and convenient maintenance

LED indicator lights display the working status of each output channel, facilitating on-site monitoring and troubleshooting.

Modular structure, convenient for installation, replacement, and system expansion.

Industrial environment adaptability

EMC has strong anti-interference ability and can operate stably in industrial environments with strong electromagnetic noise.

Adapt to a wide temperature and humidity range to meet industrial control requirements.

system compatibility

Seamless connection with PiC series controllers and other modules.

Support the control requirements of DC loads in medium and large-scale control systems.

Application field

CNC machine tools: drive fixtures, solenoid valves, lubrication pumps, and other DC actuators.

Automated production line: controls the actions of conveying machinery, sorting equipment, and assembly machinery.

Process control system: drives DC valves, pumps, and alarm devices.

Signal indication and alarm system: Drive indicator lights and buzzers to achieve status display and alarm.

Product imag
