AEG Modicon 140CFA04000 Analog Input Module

AEG MODICON  140CFA04000 Analog Input Module

Product Details Introduction

The AEG Modicon 140CFA04000, as a high-precision analog input module in the Quantum series, is equipped with 8 independent channels and is designed specifically for industrial thermocouple temperature measurement scenarios, ensuring accurate and reliable data acquisition.

Supports multiple types of thermocouple inputs such as S/R/T/K, with a measurement temperature range of -270 ℃ to 1665 ℃ for 140CFA04000, suitable for industrial temperature measurement needs in different temperature zones.

The AEG Modicon 140CFA04000 has 16 bit high-resolution conversion capability, with measurement errors as low as ± 2 ℃+± 0.1% reading, providing high fidelity data support for temperature control systems.

Input impedance>1M Ω, common mode rejection ratio ≥ 120dB (50/60Hz), outstanding anti-interference ability of 140CFA04000, suitable for complex industrial wiring environments.

The AEG Modicon 140CFA04000 has built-in disconnection and over range fault detection functions, which quickly locate anomalies through status feedback to ensure the stability of the temperature measurement link.

Compatible with the full range of Modicon Quantum I/O modules, the 140CFA04000 can be seamlessly integrated into the system through the Sub-D 50 female connector, providing strong integration convenience.

The AEG Modicon 140CFA04000 has a working temperature range of -10 ℃ to 60 ℃, and supports wide temperature operation from -40 ℃ to 70 ℃ in some scenarios, suitable for high and low temperature industrial conditions.

Adopting DIN rail installation design, the size is compact (referring to 32 × 35 × 40mm specifications), with a weight of only 0.2-0.3kg, saving control cabinet space with 140CFA04000.

The AEG Modicon 140CFA04000 is equipped with captive screw terminals, which are firmly wired and prevent loosening, effectively avoiding poor contact problems in vibration environments.

The power consumption is only 1.5W, and the 140CFA04000 low-energy design is suitable for long-term continuous operation, reducing the overall energy consumption of industrial systems.

AEG Modicon 140CFA04000 supports 10 input word address configurations and is compatible with Unity Pro programming software, making debugging and parameter settings convenient.

Equipped with 1780VAC electrical isolation protection, 140CFA04000 can withstand voltage surges, ensuring the safety of modules and system core components.

AEG Modicon 140CFA04000 has passed multiple international certifications including UL, CE, and CSA, complies with IEC industrial standards, and is suitable for automation projects in multiple regions around the world.

Widely used in industries such as chemical reaction vessels, metallurgical kilns, and food processing, 140CFA04000 provides precise data acquisition support for temperature closed-loop control.

 AEG MODICON 140CFA04000 Product imag
