AEG Modicon BKF101 Bus Inter Group Interface Module

AEG MODICON  BKF101 Bus Inter Group Interface Module

Product Details Introduction

AEG Modicon BKF101 is an industrial grade bus grouping interface module that focuses on seamless interconnection of multi bus systems.

Supports bidirectional conversion between Profinet and Modbus bus, perfectly adapting to the communication requirements of PC-A984-120 control system.

Group communication design, AEG Modicon BKF101 can group and manage different devices according to their functions, making data transmission more orderly.

Linked with the COM-DPM-K handheld teaching pendant, the bus grouping parameters can be configured on-site, and debugging does not require an upper computer.

The data transmission rate is as high as 100Mbps, and the AEG Modicon BKF101 meets the high-frequency data exchange requirements of medium and large-scale systems.

Compatible with AS-B883-001 counter module, the counting data is quickly uploaded to the PLC core through the bus.

AEG Modicon BKF101 supports independent operation of up to 8 bus groups, and fault isolation does not affect the overall system.

Wide range power supply compatible with MM-PMC2-100 power module, 8-32VDC input ensures stable power supply.

Industrial grade anti-interference design, ± 15KV ESD protection, signal transmission without packet loss in complex electromagnetic environments.

The working temperature range of AEG Modicon BKF101 is -45 ℃~85 ℃, and its adaptability to extreme working conditions is better than that of conventional modules.

Support OPC UA protocol extension, easily integrate with MES/SCADA upper system, and achieve cross platform data sharing.

Standard rail installation, AEG Modicon BKF101 modular design, seamlessly compatible with existing control cabinet layout.

Built in bus fault diagnosis function, real-time display of group communication status through TCCX1730LW touch screen.

Suitable for intelligent factory multi bus networking, large-scale water treatment system partition control, and port equipment collaborative scheduling scenarios.

The AEG Modicon BKF101 has simple wiring, supports hot swapping, and does not require stopping the overall system operation during maintenance.

AEG MODICON BKF101  Product imag
