AE 3152412-233 DC power module

AE 3152412-233 DC power module

 Introduction

AE 3152412-233 DC power module, dedicated isolated DC power supply unit for semiconductor equipment, with stable and low ripple output, suitable for AMAT process platform power supply requirements.

Product Features:

1. Built in isolation transformer, effectively isolates interference, with small output voltage ripple

2. Integrate multiple protections for overvoltage, overcurrent, short circuit, and reverse polarity to protect the backend load

3. Onboard status monitoring interface, capable of providing feedback on operational fault signals, facilitating equipment troubleshooting

4. Modular rack mounted installation, easy disassembly and replacement, shortening downtime for maintenance

5. Anti cabinet electromagnetic interference, suitable for harsh working conditions of semiconductor process equipment

Product Parameters:

1. Equipment type: isolated DC power module

2. Maximum output voltage: 250VDC

3. Equipped with voltage and current closed-loop monitoring function

4. Support fault signal output and interface with device master control

5. Working temperature: 5-50 ℃, installed inside the cabinet

Application fields:

1. AMAT Endura platform process chamber supporting power supply

2. Power supply for sub units of semiconductor metal deposition equipment

3. Power supply for vacuum process chamber sensors and driving components

4. DC load power supply for thin film processing equipment

5. Auxiliary power supply inside the wafer processing equipment cabinet

Multiple protections and stable output performance make AE 3152412-233 an important DC power supply component for semiconductor process equipment.

Product imag
