Kyoto Denkiki KDP-2T030-036 Voltage Drop Protector

Kyoto Denkiki KDP-2T030-036 Voltage Drop Protector

 Introduction

Kyoto Denkiki KDP-2T030-036 is a Kyoto Motor instantaneous voltage drop protector, which is a capacitive energy storage type, battery free and maintenance free, and can withstand the impact of power grid transients and disconnections.

Application areas

1. Transient power supply protection for semiconductor etching equipment power supply

2. Voltage drop protection for servo drive system of lithography machine

3. Power supply guarantee for thin film deposition PVD/CVD equipment

4. Protection against disturbances in the electrical network of the ion implantation machine

5. Uninterrupted power supply protection for vacuum molecular pump unit

6. Protection of RF power supply and plasma power supply

7. Power supply and voltage stabilization protection for photovoltaic coating process equipment

8. Power abnormality protection for chip testing equipment

9. Industrial precision servo control system anti transient protection

10. Power protection for key process equipment in clean factories

Product Parameters

1. Rated output capacity 30kVA, three-phase 200-240VAC ± 10% input, 50/60Hz

2. Full load protection lasts for 1 second, and light load can last up to 6 seconds to maintain energy storage

3. No battery or fan, natural air cooling, normal working efficiency of 98%

4. Built in bypass switching, with alarm relay contact output, supporting upper level monitoring

5. Compliant with SEMI F47 industrial standards and suitable for semiconductor factory operating conditions

In summary, Kyoto Denkiki KDP-2T030-036 is maintenance free, responsive, and effectively avoids process interruptions caused by voltage drops, making it a key power protection unit for semiconductor production lines
