 Introduction

Leybold 400035V0001 digital magnetic drive (MAG. DRIVE digital), a dedicated variable frequency drive unit for magnetic levitation molecular pumps.

Product Features:

1. Specially designed to provide digital variable frequency drive for magnetic levitation molecular pumps, controlling rotor suspension and speed closed-loop

2. Stable speed adjustment, achieving smooth start stop of molecular pump and reducing rotor impact

3. Real time monitoring of the magnetic bearing status to ensure the non-contact suspension and stable operation of the rotor

4. Support local panel operation, allowing viewing of speed, temperature, and fault codes

5. Equipped with complete pump body status diagnosis, abnormal output relay alarm signal

6. Compatible with PLC remote control of equipment, enabling start, stop, and status feedback

7. Rack mounted installation structure, easy disassembly, replacement, and maintenance of cabinets

8. Built in soft start logic reduces power on shock and extends pump life

9. Suitable for semiconductor production lines to operate continuously 24/7 without interruption

10. Comprehensive fault records for easy troubleshooting of vacuum systems

Product Parameters:

1. Power input: 200-240VAC, 50/60Hz

2. Maximum output frequency: 600Hz

3. Maximum pump current: 15A rms

4. Interface: Relay output, analog signal, communication interface

5. Protection: overcurrent, overtemperature, abnormal magnetic bearings, and overspeed protection

Leybold 400035V0001 is mainly used for driving and controlling magnetic levitation molecular pumps in semiconductor equipment, serving high vacuum chambers.

Product imag
