Nikon 4T070-339-1 processor module

Nikon 4T070-339-1 processor module

 Introduction

Nikon 4T070-339-1 is a plug-in processor module for DUV lithography machine cabinets, responsible for subsystem operations, data analysis, and real-time task scheduling, and collaborating with multiple boards to complete exposure process control.

Application areas

1. Real time data processing of NSR lithography machine subsystem

2. Analysis and calculation of motion data for workpiece table and mask table

3. Exposure process timing logic scheduling and task distribution

4. Parameter calculation and closed-loop control of optical lighting units

5. Preprocessing operation of raw data for alignment detection

6. Data exchange and transfer between internal boards of the lithography machine

7. Real time calculation and processing unit related to exposure dose

8. Summary and analysis of data collected by device sensors

9. Fault diagnosis data calculation and alarm preprocessing

10. Semiconductor scanning exposure equipment subsystem main control board

Product Parameters

1. Standard drawer insertion structure, compatible with lithography machine cabinet slots

2. Onboard processor unit to achieve high-speed real-time task computation

3. DC power supply inside the cabinet, PCB enhanced anti electromagnetic interference

4. Internal bus of dedicated equipment, high-speed docking with peripheral IO and amplifier boards

5. Built in hardware self-test, abnormal state output alarm signal

In summary, the Nikon 4T070-339-1 processor module has fast computational response, coordinates various data and timing of subsystems, and is the core computing board of the Nikon DUV lithography machine control system
