Silicon Graphics 040-1388-002 Power Control Board

040-1388-002 is an SGI original industrial grade power monitoring and management board used for high-end workstation/server power systems, responsible for power supply timing, voltage monitoring, and fault protection.

Model: 040-1388-002 (SGI original power control board)

Applicable: Suitable for SGI Onyx/Challenge series cabinet power supply

Core: Dedicated power management MCU, precise and controllable timing

Monitoring: Real time sampling of multi-channel voltage/current/temperature

Protection: Hardware protection against overvoltage, undervoltage, overcurrent, and overheating

Timing: multi-stage power on/off timing to protect the core board

Communication: Interact with the system motherboard and report the power status

Interface: power module docking, system bus, alarm output

Load: Supports redundant parallel connection of multiple power sources and load balancing

Calibration: onboard potentiometer, fine adjustment of voltage accuracy

Power supply: 12V/5V dual input, compatible with industrial power supply

PCB: multi-layer industrial grade, temperature resistance -20 ℃~+70 ℃

Anti interference: EMI filtering and shielding design, strong stability

Size: Standard rack mount, dedicated slot installation

Usage: SGI high-end workstations, industrial servers, redundant power systems

Product imag
