TEL 5085-404811-11 Robot Controller

TEL 5085-404811-11 Robot Controller

 Introduction

TEL 5085-404811-11 robot controller is a specialized motion control unit for wafer handling robots in Tokyo Electronic Semiconductor Equipment.

Product Features

1. Multi axis collaborative motion control, high precision in wafer handling and positioning, and small repetition error

2. Real time fault detection, capable of identifying abnormalities such as overload and position deviation and triggering protection

3. Anti electromagnetic interference, suitable for complex electromagnetic environments in semiconductor production line cabinets

4. Support device bus docking and achieve linkage scheduling with the main control system of the whole machine

5. Modular design, easy disassembly and maintenance, reducing production line downtime

Product Specifications

1. 24VDC industrial power supply, compatible with equipment cabinet power supply circuit

2. Support multi axis servo drive to achieve multi joint collaborative motion of robots

3. Equipped with multiple digital IO signal channels, connecting sensors and actuators

4. The working environment temperature is 5-45 ℃, which meets the working conditions of the clean workshop

5. Standard cabinet installation, compatible with TEL series equipment chassis storage space

Application Areas

1. TEL coating and developing equipment wafer transfer unit

2. Semiconductor etching equipment wafer manipulator control system

3. Control of internal handling robots in wafer processing equipment

4. Semiconductor process chamber wafer loading and unloading system

5. Original equipment maintenance and replacement of spare parts

The TEL 5085-404811-11 robot controller ensures stable and reliable wafer transfer and is a key motion control spare part for TEL semiconductor equipment.

Product imag
