STL 1360-00103 Transformer

STL 1360-00103 Transformer

 Introduction

STL 1360-00103 transformer is a specialized isolation transformer component for semiconductor process equipment, used for internal voltage conversion and electrical isolation of equipment.

Product Features

1. High insulation level of winding, excellent isolation performance, ensuring electrical safety of equipment

2. Low magnetic core loss, low working temperature rise, and support for long-term continuous operation

3. Anti electromagnetic interference, small output voltage fluctuation, stable power supply output

4. Compact body structure, suitable for narrow installation space in equipment cabinets

5. Seismic and dust resistant, adaptable to complex working conditions in semiconductor equipment cabins

Product Specifications

1. Industrial communication input, realizing voltage rise and fall conversion

2. The first level has high isolation and voltage resistance, and reliable insulation protection

3. Adapt to equipment cabin working temperature of 5-50 ℃

4. Integrated packaging, standardized design of wiring terminals

5. Cabinet fixed installation method, easy disassembly and maintenance

Application Areas

1. Internal power conversion of semiconductor etching equipment

2. Power supply system for thin film deposition process equipment

3. RF power supply supporting isolation transformer unit

4. Electronic control cabinet components for wafer processing equipment

5. Replacement and maintenance of spare parts for semiconductor equipment

STL 1360-00103 transformer, with its stable transformer isolation capability, is a key magnetic spare part for semiconductor equipment electrical control systems

Product imag
