AMAT 0190-91543 power module

AMAT 0190-91543 power module

 Introduction

AMAT 0190-91543 power module, a rack mounted power supply unit dedicated to semiconductor equipment, with stable and low ripple output, suitable for AMAT process platform cabinet power supply.

Product Features:

1. Multi channel isolated output, low ripple noise, protecting precision boards and sensors

2. Integrate multiple hardware protections for overvoltage, overcurrent, overheating, and short circuit

3. Comes with fault status feedback signal, making it easy for equipment to quickly locate faults

4. Rack plug-in structure, easy to disassemble and replace, reducing downtime

5. Anti electromagnetic interference, suitable for clean workshop conditions of etching and deposition equipment

Product Parameters:

1. Equipment type: Semiconductor rack mounted DC power module

2. Communication input: 200-240VAC, 50-60Hz

3. Multi channel stabilized DC output with output status monitoring

4. Built in temperature controlled fan for heat dissipation

5. Working temperature: 5-50 ℃, installed inside the cabinet

Application fields:

1. Auxiliary power supply for AMAT Centura and Endura platform cabinets

2. Power supply for process chamber sensors and solenoid valve components

3. Power supply for wafer manipulator driver board

4. Power supply for the sub control unit of the etching equipment

5. Power supply for internal electronic control components of thin film deposition equipment

Multiple protections and platform adaptability make AMAT 0190-91543 an important power supply component for semiconductor process equipment.

Product imag
