AMAT 0010-01711 Robot Driver

AMAT 0010-01711 Robot Driver

 Introduction

AMAT 0010-01711 robot driver, specialized servo drive unit for semiconductor equipment, stable output, suitable for motion control of wafer handling robots.

Product Features:

1. Servo closed-loop control, high positioning repeatability, suitable for precision wafer handling

2. Anti plasma electromagnetic interference, suitable for complex electromagnetic environments around process chambers

3. Onboard fault self check and hardware interlock, timely alarm protection equipment for abnormalities

4. Standardized board card installation, supporting quick insertion and replacement, shortening downtime maintenance time

5. Compatible with AMAT platform communication protocol, can directly interface with device control system

Product Parameters:

1. Equipment type: Robot servo drive board

2. Target audience: Semiconductor wafer transfer robotic arm

3. Working voltage: 24-48VDC

4. Supports multi axis motion control and has current overload protection

5. Working temperature: 5-50 ℃, suitable for internal working conditions of equipment cabinets

Application fields:

1. AMAT Endura and Centura platform wafer manipulator drive

2. Wafer transfer mechanism inside the etching equipment chamber

3. Material handling between the film deposition equipment box and the process chamber

4. Multi axis robot motion control for semiconductor vacuum equipment

5. Robot arm execution unit driver for wafer inspection equipment

High reliability and platform compatibility make AMAT 0010-01711 the core driving component of semiconductor process equipment manipulators.

Product imag
