 Introduction

LAM V7668A -131000 is a CPCI architecture single board computer from Panlin Semiconductor Equipment. As the main control CPU board of the machine, it is responsible for process operations and overall machine scheduling control.

Product Features:

1. CPCI plug-in card architecture, directly compatible with LAM etching equipment cabinet slots, plug and play

2. Multi port integrated design, realizing high-speed data exchange and transmission among multiple modules inside the machine

3. Onboard solid-state storage, resistant to vibration and impact, suitable for semiconductor equipment cabinet working conditions

4. Hardware watchdog protection, automatic reset upon system crash, ensuring continuous production operation of the machine

5. Industrial grade components with electrostatic protection and resistance to electromagnetic interference in the workshop

Product Parameters:

1. Model: V7668A -131000

2. Board type: CPCI architecture single board computer

3. Bus standard: CPCI Industrial Bus

4. Interface: Multiple Gigabit Ethernet ports, USB, SATA storage interfaces

5. Compatible equipment: LAM semiconductor etching process machine

Application fields:

1. LAM etching equipment main control operation and process scheduling

2. Data communication and processing between various sub modules of the machine

3. Spare parts for CPU main control board of semiconductor dry etching equipment

4. Maintenance and replacement of faulty single board computers

5. Inventory reserve of spare parts for industrial control boards in semiconductor factories

The V7668A-131000 single board computer is responsible for the core computing tasks of the machine and is the key control board of the Panlin etching equipment control system.
