TEL 5044-000233-12 Printed Circuit Board

TEL 5044-000233-12 Printed Circuit Board

 Introduction

TEL 5044-000233-12 is a printed circuit board specifically designed for semiconductor equipment, compatible with etching equipment, electrically stable, and resistant to process environmental interference.

Product Features:

1. High density wiring with low signal transmission loss

2. Temperature and corrosion resistance, suitable for semiconductor process environment

3. Accurate impedance control and good signal integrity

4. Anti vibration and impact, high reliability of equipment operation

5. The interface matches the original factory, making replacement and installation convenient

Product Parameters:

1. Substrate: FR-4 high Tg sheet

2. Surface treatment: immersion gold process

3. Working temperature: -10~70 ℃

4. Insulation resistance: ≥ 10 ¹² Ω

5. Bus adaptation: Device specific signal interface

Application fields:

1. Signal control of semiconductor etching equipment

2. Replacement of complete TEL process equipment spare parts

3. Main control circuit of wafer processing equipment

4. Internal signal acquisition of vacuum equipment

5. Semiconductor production automation unit

TEL 5044-000233-12 can meet the circuit control requirements of semiconductor process equipment under harsh working conditions
